Fittings » High Pressure Forged » 3000 # NPT Fittings » Elbows
Street Elbows
Nom. pipe Size H A A1 d d1 G (Min) B (Min) B1 (Min)
1/4" 25 22.2 31.7 11.2 7 3.30 8.0 10.3
3/8" 33 25.4 38.1 14.5 9 3.51 9.0 10.4
1/2" 38 28.6 41.2 15.7 13 4.09 11.0 13.6
3/4" 46 34.9 47.6 20.9 16 4.32 12.5 13.8
1" 56 44.5 57.2 26.6 20 4.98 14.5 17.3
1-1/4" 62 50.8 66.7 35.0 28 5.28 17.0 18.0
1-1/2" 75 54.0 71.4 40.9 30 5.56 18.0 18.4
2" 84 63.5 84.0 52.5 40 7.14 19.0 19.3
Unit : MM
Elbows Products
  • 45 Degree Elbows
  • 90 Degree Elbows
  • Street Elbows
